NL Series Commercial Filter

• Multi-construction layers: non-corrosive and chemical protective
• UV resistance, suitable for operation under prolonged sunlight
• High filtration standard with deep sand bed
• Bobbin wound fiberglass reinforcement with polyester resin
• Available with laterals or nozzle plate system for air scouring capabilities
• Optional accessories includes sight glass, manhole, union drain, and air purge.

Components:

1. Manhole Lateral Manhole for easy access to internal system maintenance and service
2.Sightglass Allow great observation on media status and backwash effect
3.Flange Heavy duty FRP flange connection in either ANSI or DIN standard
4.Manometer High quality pressure gauge to monitor the pressure inside the filter tank
5.Union Drain A quick discharge point of water and filter media
6.Lateral System Constructed by ABS+PP material with rigid structure and 0.4mm slit
7.Air Vent Valve Automatic release of air bubbles in the filtration system
8.Base Flat base increase the stability
